Technical Specifications
| Size Range
NPS 1/2″-24″?/ DN15-600mm |
Main Material
Carbon steel, Stainless Steel, Aluminum Bronze, Duplex steel etc.
(Other materials are available under request.) |
| Temperature Rating
-29?~ +180°C |
Stem Material
Stainless Steel |
| Pressure Rating
I.0Mpa?~ 4.0Mpa ?150LB?~ 600LB |
Leakage Level
Zero Leakage |
| Plug Material
Carbon Steel, Stainless Steel, Duplex Steel etc. |
Flange Drilling
ASME B16.5, EN1092, GOST 33259, BS etc. |
| Seat Material
PTFE, RPTFE |
Port Type
Reduce Port |
| Design Standard
API599, API 6D, ASME B16.34 |
Test Standard
API 598, EN12266-1, ISO 5208, API 6D |
| Face to Face
API 16.10,EN558-1,API 599 |
Operation
Lever, Worm Gear, Electric, Pneumatic, etc. |
| Application
On the pipelines of various working conditions such as petroleum, chemical, pharmaceutical, fertilizer, and electric power industries, cut off or connect the pipeline medium. |
| Other
The carefully selected materials and contemporary design make our plug valve highly recognized.
If our Plug Valve cannot meet your choice, we can provide you with special made. |
Chief Features
The product has reasonable structure, reliable sealing, excellent performance and beautiful appearance;
Its tightness is achieved by the sealing surface around the ferrule. Unique 360°metal lip secures the ferrule.
The valve has no cavity for media to accumulate.
The metal lip provides self-cleaning when the cock rotates and is suitable for viscous and fouling-prone conditions.
Two-way flow, more convenient to install and use.
PTFE, a high-quality composite sealing material, closely fits the valve body, with compact structure, low friction with the plug, better sealing performance and longer service life.
